MICC CABLE'S IDENTIFICATION
Characters
|
voltage
|
Model
|
core
|
Cross section mm2
|
Light load
|
500V
|
BTTQ
|
1、2、3、4、7
|
1-4
|
BTTVQ
|
1、2、3、4、7
|
1-4
|
WD-BTTYQ
|
1、2、3、4、7
|
1-4
|
Heavy load
|
750V
|
BTTZ
|
1、2、3、4、7、10、12、19
|
1-400
|
BTTVZ
|
1、2、3、4、7、10、12、19
|
1-400
|
WD-BTTYZ
|
1、2、3、4、7、10、12、19
|
1-400
|
MICC CABLE'S ADVANTAGES
1. Fireproof:As the melting point of copper is
1083 ℃ and that of magnesium oxide is 2800 ℃, MICC cable can continue to supply
power in case of fire near the melting point of copper, which is a kind of real
fireproof cable. It is currently the only safety cable that can maintain a
power supply capacity of three hours in a fire at 1000°C and withstand the impact of fire water sprinklers and
heavy object falls.
2.Large ampacity and overload resistance: The thermal
conductivity of magnesium oxide insulation material is large and the heat
dissipation is good. The current of mineral insulated cables is large; its
overload capacity can reach more than 10 times the normal current carrying
capacity.
3.Waterproof and explosion proof : Seamless copper pipe
sheath isolates water molecules and has a good waterproof effect. Also,
combustible gases, oil vapors, and flames cannot reach electrical equipment
connected to cables;
4.High temperature and corrosion resistance: As MICC cable
is made of copper, this material can withstand high temperature. With the
protect of plastic sheath, the cable can work in severely corrosive
environment;
5.Environmentally friendly: Under fire conditions the
cable does not spontaneously combust and does not produce smoke and toxic
gases; due to the continuity of the copper sheath and the extremely low ground
resistance, it can be used as a ground conductor, which saves a single
protective ground wire;
6.Long lifespan : When the cable is subjected to impact
bending, squashing, torsion, etc., the sheath will not be damaged, and the
relative position between the core wires and between the core and the sheath
will remain unchanged, and there will be no short circuit and no impact on
electrical performance. Sheath oxidation 0.25mm takes 257 years at an ambient temperature
of 250°C.
MICC CABLE'S APPLICATION
1. High-rise buildings
General lighting, emergency lighting, fire alarm, fire electrical lines, emergency elevators and lifting equipment lines, computer room control lines, trunk/sub-trunk distribution system lines, dual power supply control lines;
2. Airport terminals
General lighting and power supply, emergency lighting, fire monitoring
systems, fire alarm systems, fire electrical wiring;
3. Subway, light rail, road
General lighting, emergency lighting, fire alarm, fire
electrical wiring, ventilation wiring and life-saving systems;
4. Shopping malls, hotels, hospitals
General lighting, emergency lighting lines, emergency broadcast lines, emergency elevators, fire lines and lifting equipment lines;
5. Conference center, sports center, theater
General lighting, emergency lighting lines, emergency broadcast lines, emergency elevators and lifting equipment lines;
6. Libraries, museums, data processing centers
General lighting, emergency lighting
lines, fire alarm control lines, fire electrical lines;
7. Parking, underground garage, civil air defense
General lighting, emergency lighting, fire alarm, fire lines and
ventilation lines;
8. Historic sites
General lighting, emergency lighting, fire alarm, fire electrical
wiring;
9. Petrochemical, petroleum platform
General lighting, emergency lighting lines, high-temperature places, fire lines, large power lines, potentially dangerous explosion area lines;
10. Warships, ships
Generator room transmission lines, fire monitoring systems, fire alarm systems, flue gas emission and ventilation lines, kitchen power lines, large power lines, dual power control lines, emergency lighting, emergency broadcast lines, computer room control lines;
11. Iron and steel metallurgy
High temperature environment power and control lines, emergency power
supplies, large power lines, power supply lines that cannot be cut off,
generator room transmission lines;
12. power plant
Large power lines, general lighting, emergency lighting, fire alarm,
fire electrical lines;
13. Power plants, nuclear power plants, aerospace
General lighting, emergency lighting lines, computer room control lines,
large power lines, high temperature environment power and control lines,
potentially dangerous explosion area lines;
14. Oil depots, ammunition depots,aviation and aerospace
General lighting, emergency lighting, fire alarm, flue gas
emissions, flammable and explosive and ventilation lines;
15. Industry Smoke exhaust fans, high-frequency heating furnaces, high-temperature
places, fire lines, large power lines.
We supply the top quality MICC cable 100% through QA program supervised by the Chief Quality Officer. Continuously doing the job of raw materials purchase management, manufacturing processes optimization, staff training,etc. Our sales prices can always keep competitive all over the world.
If you have a special application, pls contact our sales department to find out the solution, we will be waiting here at 7*24.
