Pure nickel wire

Bellows Pressure Gauge uses a diaphragm as a sensitive element for measuring minute pressures. It measures low and negative pressures in gases that are non-corrosive to copper alloys and non-explosive. It is widely used in cobalt furnace ventilation, gas pipelines, combustion equipment, and other similar equipment. Bellows Pressure Gauge consists of a measuring system (including connectors, diaphragm), a transmission mechanism, an indicating device, and a housing.When the pressure of the measured medium acts on the diaphragm, its free end undergoes a corresponding elastic deformation—displacement. This displacement is amplified by a lever-driven transmission mechanism, and the indicating device displays the measured pressure on the instrument dial.

The Stainless Steel Industrial Pressure Gauge consists of a pressure-guiding system (including connectors, spring tube, etc.), a gear transmission mechanism, an indicating device, and a housing. All components are made of stainless steel. When the spring tube is subjected to the pressure of the measured medium, its end undergoes corresponding elastic deformation, which is amplified by the gear transmission mechanism and displayed on the dial by the indicating device. The Stainless Steel Industrial Pressure Gauge's housing is sealed, effectively protecting the internal components from environmental influences and contaminants. Furthermore, the oil filling inside the housing provides resistance to pressure fluctuations of the measured medium and severe vibrations in the operating environment, ensuring both corrosion resistance and shock resistance.

Type J thermocouple alloys is suitable for using in vacuum, oxidizing and reducing atmospheres or inert gas atmospheres. Because of high temperature oxidizing quickly for JP, the measuring temperature range is restricted. The composition of positive(JP) is Fe100, negative(JN) is Cu55Ni45 for Type J bare thermocouple wire .

Type C thermocouple wire is a tungsten-rhenium alloy wire, and the material composition is tungsten-rhenium 5 &tungsten-rhenium 26 (WRe5-WRe26). The melting point of tungsten-rhenium thermocouple wire is 3120-3360℃, and it can be used up to 3000℃. It is the most high-temperature resistant metal thermocouple, and it has excellent characteristics such as high thermoelectric potential, high sensitivity, high temperature stability, oxidation resistance and corrosion resistance.

The RTD probe is composed of an element,sheath,lead wire and connector, it is working principle is the resistance of a metal changes with temperature.An electrical current is transmitted through the RTD element located in proximity to the area where temperature is to be measured, the resistance value is then measured by an instrument. SICC is your one-stop solution providing Automotive RTD probe that will meet your needs, Contact us today for more information!

Mineral insulated RTD cable with Nickel conductors is the normal type for RTD cable for high temperature measurments up to 600C. The Mineral insulated RTD cable  are the base material for RTD sensors, its structure advantage with anti pollution and mechanical strength promise can be applied in the harsh environment.

Type E Bare thermocouple wire develops the highest source voltage(EMF) per℃ for measuring tiny temperature shift,it is suitable in oxidizing or inert gas atmospheres up to 900℃(ASTM E230:870℃),  The composition of positive(EP) is Ni90Cr10, negative(EN) is Cu55Ni45 for type E thermocouple wire material. SICC is your one-stop solution providing Type E Bare thermocouple wire that will meet your needs, Contact us now for more inquiries!

Bimetallic thermometers are constructed by welding two metal sheets with different linear expansion coefficients based on the thermal expansion characteristics of a bimetallic strip. When the temperature changes, the bimetallic strip bends due to the change in expansion coefficient, causing the pointer to indicate the corresponding temperature on the arrow.
